Under Bench Safety Storage Cabinet UB90.060.110.2T, 90 Min Fire Rated, EN 14470-1
- Model range: Safety Storage Under Bench Cabinets
- Model line: UB-LINE
- Model group: UB-T-90
- Model: UB90.060.110.2T
- External dimensions W x D x H (mm): 1102 x 574 x 600
- Internal dimensions W x D x H (mm): 979 x 452 x 502
- Weight excluding packaging (kg): 177.5
- Tariff Number: 94032080
- GTIN: 4054923137646
- Item Code: 30443-001-33771
- Colour: Body and Door(s): Light grey (RAL 7035)
- Optional accessories and technical ventilation are available and purchased separately.
- Installation is required.
Optional accessories are available for purchase separately. If you require a customised solution, please get in touch with our technical specialists by selecting the “Add to enquiry” button and using our enquiry form or by emailing [email protected].
Installation, training and special delivery requirements, such as the need for tail-lift trucks and additional labour and installation for large equipment and hazardous material (Hazmat) packaging, are chargeable in addition to standard freight and will be quoted separately before dispatch.
Online ordering is currently limited to South African customers, but our full range is still available. If you are ordering from outside South Africa, please log an enquiry or email [email protected], and our international sales team will gladly assist you through our traditional sales channels.
Description
Product Overview
UB-LINE: Under bench safety storage cabinets for space-saving integration under fume hoods, hazardous materials workstations or work surfaces.
The asecos UB90.060.110.2T underbench safety cabinet is designed for the safe and compliant storage of flammable hazardous materials directly within laboratory working areas. Engineered for space-saving installation under fume hoods or work surfaces, this cabinet maximises available laboratory space without compromising safety.
Manufactured from powder-coated sheet steel, the cabinet provides robust construction, long service life, and high chemical resistance. With 90-minute fire resistance (Type 90) and compliance with key European safety standards, it ensures maximum protection for personnel and facilities.
The UB-LINE offers flexible configurations, efficient ventilation options, and user-friendly access, making it ideal for modern laboratory environments.
Key Features
Certified Safety & Compliance
- 90-minute fire resistance (Type 90)
- Type-tested to EN 14470-1
- Conforms to EN 16121 / EN 16122
- GS certified and CE compliant
- Suitable for safe storage of flammable hazardous materials
Space-Saving Underbench Design
- Designed for installation under fume cupboards and work surfaces
- Optimises laboratory space without compromising accessibility
- Available in multiple size configurations (UB-LINE range)
Robust Construction
- Body made from powder-coated sheet steel
- Durable and corrosion-resistant design
- Long service life under demanding laboratory conditions
Ventilation & Safety
- Integrated air ducts (DN 50) for connection to exhaust systems
- Prevents build-up of hazardous vapours and explosive atmospheres
- Compatible with optional recirculating air filter system
User-Friendly Operation
- Wing doors with 93° opening angle for full access
- Doors remain open in any position
- Full visibility of cabinet contents
- Optional drawers for improved organisation
Secure Storage
- Cylinder lock with red/green locking status indicator
- Prevents unauthorised access
Flexible & Mobile Options
- Optional castors with plinth for mobility
- Adjustable height for compatibility with laboratory furniture
- Modular internal configurations available
Internal Configuration
- Number of storage levels: 1
- Storage type: Perforated insert
- Material: Sheet steel (powder-coated)
- Maximum load per shelf: 75 kg
- Bottom collecting sump capacity: 25..L
Storage Capacity
- 1 L glass bottles: 36
- 1 L PE bottles: 36
- 5 L glass bottles: 12
Construction & Function
- Doors self-close automatically in case of fire
- Doors remain open in any position during use
- Full interior visibility for easy access
- Integrated ventilation system connection
- Designed for safe handling and efficient workflow
Ventilation Options
- Connection to external exhaust system (DN 50)
- Optional recirculating air filter system:
- Designed for low internal cabinet volume
- Can be mounted on console or housing unit
Optional Features & Accessories
- Castors with plinth for mobility
- Recirculating air filtration system
- Additional drawers and storage configurations
Finish & Design
- Colour: Light grey (RAL 7035)
- Clean, professional laboratory appearance
- Designed for integration into modern lab environments
Compliance & Identification
| Attribute | Value |
| eCl@ss | 40-06-01-04 |
| UNSPSC | 24112402 |
| Customs Tariff | 94032080 |
| GTIN | 4054923137646 |
Typical Applications
- Storage of flammable chemicals in laboratories
- Pharmaceutical and research facilities
- Chemical and industrial laboratories
- Educational and institutional labs
- Workstations under fume hoods
Advantages
- Certified Type 90 fire protection
- Space-saving underbench installation
- High load capacity and durable construction
- Safe ventilation and vapour control
- Flexible configuration options
- Secure and user-friendly design
